UHP 600mm Graphite Electrode with nipple

UHP 600mm Graphite Electrode with nipple

Inquire Now Next Product

Description

Diameter: 600mm/24 inch

Length: 2100mm/2400mm/2700mm

Grade: UHP (Ultra High Power)

Nipple: 4 TPI/4 TPIL/ T4N/ T4L

Application: EAF （Electric arc furnace) / LF (Ladle Furnace)

Color: BLACK GREY

Place of Origin: Hebei China (Mainland)

Brand Name: Hengqiang

Technical Data

Item	Classification	Unit	Nominal Diameter
Item	Classification	Unit	600mm
Electrical resistivity (≯)	Pole Nipple	μΩm	5.5 3.5
Bending strength (≮)	Pole Nipple	Mpa	11.0 20.0
Young's modulus (≯)	Pole Nipple	Gpa	14.0 22.0
Bulk density (≮)	Pole Nipple	g/cm³	1.68 1.8
Thermal expansion coefficient (≯) (100℃-600℃) CTE	Pole Nipple	×10^-6/℃	1.4 1.2
Ash content (≯)		%	0.2

Note: CTE and ash content are only for reference.

PRODUCT DESCRIPTION

Graphite electrode, mainly made of high quality petroleum coke and needle coke, coal tar pitch as binder, is prepared by calcination, compounding, kneading, pressing, roasting, graphitization and machining. According to the quality, it can be divided into regular power, high power and ultra high power.

APPLICATION

Ultra high-power graphite electrodes are mainly used in steel smelting process utilizing large capacity EAF (Electric Arc Furnace) and in LF (ladle refining furnace). The UHP electrodes are impregnated with special pitch in the furnace to increase their strength and density.

ADVANTAGE

Obtained ISO 9001

More than 20 years of factory experiences

Low consumption and more durable

Strict quality control from raw materials to finished products

Advanced production technology and strong technical force

Export to more than 20 countries and areas like Russia, Vietnam, India, Bangladesh, Turkey, Iran etc.

PRODUCT FEATURE

Good electrical conductivity

Strong thermal shock resistance

Low electrical resistivity

Ultra-high bending resistance
